SERVICE FEES **
Standard Delivery Schedule:
No more than five business days after receipt of design drawings and the retainer services fee.
An additional fee (30% to 60%) may apply to a requested delivery of three business days or less when business conditions warrant due to abnormally high demand.
Additional fee will not apply to a BLOCK LOAD calculation for NEW Construction and < 2,800 square feet floor area.
BLOCK LOAD calculation fee ranges from $0.052 ( < 1,600 Sq.Ft.) to $0.061 ( < 5,900 Sq. Ft.) per Square Foot Floor Area.
_ ACCA MANUAL J / N CALCULATION, ROOM-BY-ROOM LOADS _
| ROOM-BY-ROOM | ACCA J Calculations | SERVICE | |
| CLASS SQUARE FEET | ~ $ / Square Foot | FLOOR AREA | __ FEE __ |
| 1 < 1,600 | $0.104 | 1,500 | $156 |
| 2 < 2,400 | $0.110 | 2,100 | $231 |
| 3 < 3,400 | $0.113 | 2,700 | $305 |
| 4 < 5,900 | $0.119 | 3,500 | $416 |
| *** | DUCT SIZING | ACCA D Calculations ** | SERVICE |
| CLASS SQUARE FEET | ~ $ / Square Foot | FLOOR AREA | __ FEE __ |
| 1 < 1,600 | $0.060 | 1,500 | $90 |
| 2 < 2,400 | $0.064 | 2,100 | $134 |
| 3 < 3,400 | $0.070 | 2,700 | $189 |
| 4 < 5,900 | $0.073 | 3,500 | $256 |
ACCA MANUALS J, S & D CALCULATIONS – Packaged Fees
| ACCA MANUALS | J, S & D Calculations | SERVICE | |
| Class < Sq.Ft. | ~ $ / Square Foot | FLOOR AREA | __ FEE __ |
| 1 < 1,600 | $0.20 | 1,500 | $ 300 |
| 2 < 2,400 | $0.21 | 2,100 | $ 441 |
| 3 < 3,400 | $0.22 | 2,700 | $ 594 |
| 4 < 5,900 | $0.24 | 3,500 | $ 840 |
** Formal drawing with a detailed duct layout is NOT included in these calculation fees. A simplified sketch of the duct layout can be provided with an ACCA Manual D calculation.
*** Duct layout concepts and responsibility is to be determined at the time of invoicing based on any specific request by clients, mechanical contractor, architectural drawings and the AHU location(s).
Final pricing and schedule to be verified based on review of the architect, owner, contractor or builder submitted project information.
ACCA Manual D Basic Concepts are briefly illustrated and References are addressed on the following pages.
SIMPLIFIED HVAC and MECHANICAL SYSTEMS DESIGN, LLC
Keep It Simple
